Accuracy Class |
±(0.5%+3) |
Measuring Current Range |
0-20A |
|
Measuring Voltage Range |
0-1000 V |
Parameters Measured |
AC Voltage, AC Current, Capacitance, DC Current, DC... |
|
Place of Origin |
Guangdong, China |
Model Number |
FR890C,FR890D |
|
Brand Name |
FUZRR |
Application |
Household Use, Industrial Use |
|
Digits Displayed |
3 Digits |
Dimensions |
183×91×45mm |
|
Feature |
Standard |
Low Battery Indicator |
Yes |
|
Material |
Plastic |
Max. AC Current |
20A |
|
Max. AC Voltage |
1000 V |
Max. DC Current |
20A |
|
Max. DC Voltage |
1000 V |
Measuring Capacitance... |
100000μF |
|
Measuring Inductance Range |
20.00MHz |
Measuring Resistance Range |
60.00MΩ |
|
Operating Temperature |
0-40℃ |
Safety rating |
CAT II 1000V CAT III 600V |
|
Product range |
FR890D FR890C Semi-Automatic |
Maximum display |
FR890D FR890C display 6000 |
|
Sampling rate |
3 times/S; Overload display OL |
Auto power off |
Auto power off |
|
Operating temperature |
0-40℃ |
Precision |
23℃±5℃(18-28℃,humidity<75%)1year |
|
Safety certification |
CE EN61010-1-2-030 |
Battery-powered |
AA 1.5VX2 |
|
Electromagnetic environment |
EN61326-1-2 |
||
|
Selling Units |
Single item |
Single package size |
20X12X7 cm |
|
Single gross weight |
0.590 kg |
||
|
Function / Model
|
FR890D MAX
|
FR890C MAX
|
Accuracy
|
|
DC Voltage (V)
|
60.00mV / 600mV
6V / 60V / 600V (AUTO) 1000V |
60.00mV / 600mV
6V / 60V / 600V (AUTO) 1000V |
±(0.5%+3)
±(0.5%+3) ±(0.8%+5) |
|
AC Voltage (v)
|
6V / 60V / 600V / Hz (AUTO)
1000V |
6V / 60V / 600V / Hz (AUTO)
1000V |
±(0.8%+5)
±(1%+5) |
|
ACV / Bandwidth (Hz)
|
1KHz
|
1KHz
|
-
|
|
DC Current (A)
|
600uA
6mA / 60mA / 600mA (AUTO) 6.000A / 20A |
600uA
6mA / 60mA / 600mA (AUTO) 6.000A / 20A |
±(0.8%+5)
±(0.8%+5) ±(2%+5) |
|
AC Current (A)
|
600uA
6mA / 60mA / 600mA (AUTO) 6.000A / 20A |
600uA
6mA / 60mA / 600mA (AUTO) 6.000A / 20A |
±(1%+5)
±(1%+5) ±(2%+5) |
|
AC/DC 600A
(Current Clamp) |
0.1A ~ 600.0A (Input 1A=1mV)
|
0.1A ~ 600.0A (Input 1A=1mV)
|
±(3%+5)
|
|
Frequency (Hz) Duty
|
-
|
10Hz ~ 20MHz
10% ~ 90% |
±(0.8%+5)
±(1%+5) |
|
Resistance (Ω)
|
600Ω
6KΩ / 60KΩ / 600KΩ (AUTO) 6MΩ / 60MΩ |
600Ω
6KΩ / 60KΩ / 600KΩ (AUTO) 6MΩ / 60MΩ |
±(2%+5)
±(1%+4) ±(2.5%+4) |
|
Capacitance (F)
|
60nF / 600nF / 6uF / 60uF / 600uF / 6mF / 100mF
|
60nF / 600nF / 6uF / 60uF / 600uF / 6mF / 100mF
|
±(4%+4)
±(8%+4) |
|
HFE(NPN / PNP)
|
0~1000
|
0~1000
|
-
|
|
Battery Test
|
1.5V / 9V
|
-
|
±(2.5%+4)
|
|
Temperature (°C)
|
-
|
(-50°C~1000°C)
|
±(1.5%+4)
|
|
Temperature (°F)
|
-
|
(-58°C~1832°F)
|
±(2%+4)
|
|
FEATURES
|
|||
|
Display Counts
|
6000
|
||
|
Auto Range
|
Semi-Automatic
|
||
|
True RMS
|
|||
|
Connuity / Diode
|
|||
|
Connuity (Green LED)
|
|||
|
Power
|
AA1.5V×2
|
||
|
Category Ratings
|
CAT III 600V CAT II 1000V
|
||
|
DCV
Range |
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
60.00mV
|
60.00mV
|
0.01mV
|
±(0.5%+3)
|
|
|
600.0mV
|
600.0mV
|
0.1mV
|
||
|
6.000V(AUTO)
|
6.000V(AUTO)
|
0.001V
|
||
|
60.00V(AUTO)
|
60.00V(AUTO)
|
0.01V
|
||
|
600.0V(AUTO)
|
600.0V(AUTO)
|
0.1V
|
||
|
1000V
|
1000V
|
1V
|
±(0.8%+5)
|
|
|
Input protection
|
Impedance 10MΩ； 1000Vrms
|
|||
|
ACV
Range |
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
6.000V(AUTO)
|
6.000V(AUTO)
|
0.001V
|
±(0.8%+5)400Hz;
±(1.2%+5)1KHz |
|
|
60.00V(AUTO)
|
60.00V(AUTO)
|
0.01V
|
||
|
600.0V(AUTO)
|
600.0V(AUTO)
|
0.1V
|
||
|
1000V
|
1000V
|
1V
|
||
|
Input protection
|
Impedance 10MΩ；1000Vrms
|
|||
|
Hz
Range |
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
10.00Hz
|
10.00Hz
|
0.01Hz
|
±(0.5%+5)
|
|
|
100.0Hz
|
100.0Hz
|
0.1Hz
|
||
|
1.000KHz
|
1.000KHz
|
0.001KHz
|
||
|
60KHz
|
60KHz
|
0.01KHz
|
||
|
Input protection
|
1000Vrms
|
|||
|
Ω
Range |
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
600.0Ω
|
600.0Ω
|
0.1Ω
|
±(1%+5)
|
|
|
6.000KΩ（AUTO）
|
6.000KΩ（AUTO）
|
0.001KΩ
|
||
|
60.00KΩ（AUTO）
|
60.00KΩ（AUTO）
|
0.01KΩ
|
||
|
600.0KΩ（AUTO）
|
600.0KΩ（AUTO）
|
0.1KΩ
|
||
|
6.000MΩ
|
6.000MΩ
|
0.001MΩ
|
±(2.5%+5)
|
|
|
60.00MΩ
|
60.00MΩ
|
0.01MΩ
|
||
|
Input protection
|
1000Vrms
|
|||
|
Function
|
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
Continuity
|
0.1-30Ω
|
0.1Ω
|
||
|
Diode
|
0.500V-0.800V
|
0.001V
|
||
|
NCV
|
50V-1000V
|
50V-1000V
|
0-5cm Non-contact induction
|
|
|
LIVE
|
50V-1000V
|
50V-1000V
|
Measure the live line
|
|
|
Input protection
|
1000Vrms
|
|||
|
DCA
Range |
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
600.0uA
|
600.0uA
|
0.1uA
|
±(0.8%+5)
|
|
|
6.000mA(AUTO)
|
6.000mA(AUTO)
|
0.001mA
|
||
|
60.00mA(AUTO)
|
60.00mA(AUTO)
|
0.01mA
|
||
|
600.0mA(AUTO)
|
600.0mA(AUTO)
|
0.1mA
|
||
|
6.000A
|
6.000A
|
0.001A
|
±(2%+5)
|
|
|
20.00A
|
20.00A
|
0.01A
|
||
|
Input protection
|
FUSE:500mA/250V;20A/250V;Φ5x20mm;20A Test time Max 10S
|
|||
|
ACA
Range |
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
600.0uA
|
600.0uA
|
0.1uA
|
±(1%+5)400Hz
±(1.5%+5)1KHz |
|
|
6.000mA(AUTO)
|
6.000mA(AUTO)
|
0.001mA
|
||
|
60.00mA(AUTO)
|
60.00mA(AUTO)
|
0.01mA
|
||
|
600.0mA(AUTO)
|
600.0mA(AUTO)
|
0.1mA
|
||
|
6.000A
|
6.000A
|
0.001A
|
±(2%+5)
|
|
|
20.00A
|
20.00A
|
0.01A
|
||
|
Input protection
|
FUSE:500mA/250V;20A/250V;Φ5x20mm;20A Test time Max 10S
|
|||
|
Battery
Range |
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
1.500V
|
-
|
0.001V
|
±(2%+5)
|
|
|
9.00V
|
-
|
0.01V
|
||
|
Input protection
|
||||
|
℃/℉
Range |
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
-
|
-50℃-0℃
|
1℃
|
4℃
|
|
|
-
|
0℃-100℃
|
1℃
|
±(1.5%+4)
|
|
|
-
|
100℃-1000℃
|
1℃
|
||
|
-
|
-58℉-32℉
|
1℉
|
5℉
|
|
|
-
|
32℉-212℉
|
1℉
|
±(2%+5)
|
|
|
-
|
212℉-1832℉
|
1℉
|
||
|
Input protection
|
1000Vrms
|
|||
|
Range
|
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
6.000nF
|
6.000nF
|
0.001nF
|
±(4%+5)
|
|
|
60.00nF
|
60.00nF
|
0.01nF
|
||
|
600.0nF
|
600.0nF
|
0.01nF
|
||
|
6.000uF
|
6.000uF
|
0.001uF
|
||
|
60.00uF
|
60.00uF
|
0.01uF
|
||
|
600.0uF
|
600.0uF
|
0.1uF
|
||
|
6000uF
|
6000uF
|
0.001mF
|
±(8%+5)
|
|
|
100000uF
|
100000uF
|
0.1mF
|
||
|
Input protection
|
1000Vrms
|
|||
|
Current Clamp
|
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
6.0A(AD/DC)
|
6.0A(AD/DC)
|
0.1A
|
±(3%+5)
|
|
|
60.0A(AD/DC)
|
60.0A(AD/DC)
|
0.1A
|
||
|
600.0A(AD/DC)
|
600.0A(AD/DC)
|
0.1A
|
||
|
Input protection
|
1000Vrms;Current clamp output: 1A/1mV AC
|
|||
|
Hz
Range |
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
10.00Hz
|
10.00Hz
|
0.01Hz
|
±(0.5%+5)
|
|
|
100.0Hz
|
100.0Hz
|
0.1Hz
|
||
|
1.000KHz
|
1.000KHz
|
0.001KHz
|
||
|
10.00KHz
|
10.00KHz
|
0.01KHz
|
||
|
100.0KHz
|
100.0KHz
|
0.1KHz
|
||
|
1.000MHz
|
1.000MHz
|
0.001MHz
|
||
|
20.00MHz
|
20.00MHz
|
0.01MHz
|
||
|
Duty cycle
|
10-90%
|
10-90%
|
0.1%
|
±(1%+5)
|
|
Input protection
|
1000Vrms;10Hz-100KHz/≤200mVrms;100KHz-10MKHz/ ≤500mVrms
|
|||
|
hFE
Range |
FR890D
|
FR890C
|
Resolution
|
Accuracy
|
|
-
|
NPN 9014
|
1β
|
200-400β
|
|
|
-
|
PNP 9015
|
1β
|
200-400β
|
