| Accuracy Class | ±(0.5%+3) | Measuring Current Range |
0A～10 A |
| Measuring Voltage Range |
0-1000V | Parameters Measured |
AC Voltage,AC Current, Conductance,DC Current,D… |
| Place of Origin | Guangdong,China | Model Number | FR17B |
| Brand Name | FUZRR | Application | Household Use,Industrial Use |
| Digits Displayed | 3 Digits | Dimensions | 183*91*45mm |
| Feature | Standard | Low Battery Indicator |
Yes |
| Material | Plastic | Max.AC Current | 10A |
| Max.AC Voltage | 1000 V | Max.DC Current | 10A |
| Max.DC Voltage | 1500 V | Measuring Capacitance.…. |
0-6000OuF |
| Measuring Inductance Range |
0-20MHz | Measuring Resistance Range |
0-60.00MΩ |
| Operating Temperature |
0-40℃ | Safety rating | CATII 1000V CATⅢ 600V |
| Product range | AUTO | Maximum dsplay | FR15B+FR17B+display 6000 |
| Sampling rate | 3 times/S;Overload display OL | Auto power off | About 15 minutes |
| Operating temperature |
0-40℃ | Safety certification | CE EN61010-1-2-030 |
| Electromagnetic environment |
EN61326-1-2 | Precision | 23C±5℃(18- 28°C;humidity<75%);1year |
| Storage temperature |
-10-60°C;humidity≤80% | ||
| Selling Units | Single item | Single package size | 21X12X6 cm |
| Single gross weight | 0.600 kg |
|
Function / Model
|
FR15B+
|
FR17B+
|
Accuracy
|
|
DC mV
|
60.00mV / 600mV
|
60.00mV / 600mV
|
±(0.5%+3)
|
|
DC V
|
6V / 60V / 600V / 1000V
|
6V / 60V / 600V / 1500V
|
±(0.5%+3)
|
|
AC mV
|
60.00mV / 600.0mV
|
60.00mV / 600.0mV
|
±(0.8%+5)
|
|
ACV / Bandwidth (Hz)
|
6V / 60V / 600V / 1000V / 1KHz
|
6V / 60V / 600V / 1000V / 1KHz
|
±(0.8%+5)
|
|
VFD (AC Voltage) Variable Frequency
|
100 ~ 600V / 400Hz
|
100 ~ 600V / 400Hz
|
±(4%+5)
|
|
DC Current (A) |
600.0uA
6mA / 60mA / 600mA 6.000A / 10A |
600.0uA
6mA / 60mA / 600mA 6.000A / 10A |
±(0.8%+5)
±(0.8%+5) ±(1.5%+5) |
|
AC / DC 600A
|
0.1A ~ 600.0A (Input 1A = 1mV)
|
0.1A ~ 600.0A (Input 1A = 1mV)
|
±(3%+5)
|
|
Frequency (Hz)
Duty% |
10Hz ~ 20MHz
10% ~ 90% |
10Hz ~ 20MHz
10% ~ 90% |
±(0.5%+5)
±(2%+5) |
|
Resistance (Ω)
|
600Ω / 6KΩ / 60KΩ / 600KΩ 6MΩ / 60MΩ
|
600Ω / 6KΩ / 60KΩ / 600KΩ 6MΩ / 60MΩ
|
±(0.8%+5)
±(2.5%+5) |
|
Capacitance (F)
|
60nF ~ 600nF ~ 600uF 6000uF ~ 60000uF
|
60nF ~ 600nF ~ 600uF 6000uF ~ 60000uF
|
±(4%+5)
±(8%+5) |
|
Temperature (°C)
|
-
|
(-50°C ~ 1000°C)
|
±(1.5%+4)
|
|
Temperature (°F)
|
-
|
(-58°C ~ 1832°F)
|
±(2%+4)
|
|
FEATURES
|
|||
|
Display Counts
|
6000
|
||
|
Auto Range
|
Auto
|
||
|
True RMS
|
have
|
||
|
Connuity / Diode
|
have
|
||
|
Connuity (Green LED)
|
have
|
||
|
Power
|
AA1.5V×3
|
||
|
Category Ratings
|
CAT III 600V CAT II 1000V
|
||
