| Accuracy Class | ±(0.5%+5) | Measuring Current Range |
0-10A |
| Measuring Voltage Range |
0-600 V | Parameters Measured |
AC Voltage,AC Current,DC Current,DC Voltage,… |
| Place of Origin | Guangdong,China | Model Number | FR133D,FR133C,FR133E |
| Brand Name | FUZRR | Application | Household Use,Industrial Use |
| Digits Displayed | 3 Digits | Dimensions | 143*73*42mm |
| Feature | Intrinsically Safe,Standard | Low Battery Indicator |
Yes |
| Material | Plastic | Max.AC Current | 10A |
| Max.AC Voltage | 600V | Max.DC Current | 10A |
| Max.DC Voltage | 600 V | Measuring Capacitance.…. |
0-40000uF |
| Measuring Inductance Range |
- | Measuring Resistance Range |
0-40MΩ |
| Operating Temperature |
0-40℃ | Safety rating | CAT Ⅱ 600V |
| Product range | FR133D manual,FR133C FR133E Semi-Automatic |
Maximum display | FR133D FR133C display 2000;FR133E display 4000 |
| Sampling rate | 3 times/S;Overload display OL | 3 times/S; Overload display.. |
About 15 minutes |
| Operating temperature |
0-40℃ | Precision | 23℃±5C(18- 28°℃;Humidity<75%);1year |
| Storage temperature |
-10-60°℃;Humidity≤80% | Altitude | 0-2000M |
| Safety certification | CE EN61010-1-2-030 | ||
|
Function / Model
|
FR133D
|
FR133C
|
FR133E
|
Accuracy
|
|
AC Voltage (V)
|
600V
2V / 20V / 200V |
600V
2V / 20V / 300V(AUTO) |
750V
4V / 40V / 400V (AUTO) |
±(1%+5)
±(0.8%+3) |
|
DC Voltage (v) |
600V
2V / 20V / 200V 200mV |
600V
2V / 20V / 300V(AUTO) 200mV |
1000V
4V / 40V / 400V (AUTO) 400mV |
±(0.5%+3) |
|
ACV / Bandwidth (Hz)
|
400Hz
|
400Hz
|
400HZ
|
-
|
|
Frequency (Hz)
|
-
|
-
|
10HZ ~ 40KHZ
|
±(0.5%+5)
|
|
DC Current (A) |
2000uA / 20mA / 200mA
- 10A |
2000uA / 20mA / 200mA
- 10A |
400uA
4mA / 40mA / 400mA (AUTO) 10A |
±(1%+5)
±(1%+5) ±(2%+5) |
|
AC Current (A) |
2000uA / 20mA / 200mA
- 10A |
2000uA / 20mA / 200mA
- 10A |
400uA
4mA / 40mA / 400mA (AUTO) 10A |
±(1%+5)
±(1%+5) ±(2%+5) |
|
Resistance (Ω) |
-
200Ω / 2KΩ / 20KΩ 200KΩ / 20MΩ |
-
200Ω / 2KΩ / 20KΩ 200KΩ / 20MΩ |
400Ω
4KΩ/40KΩ/400KΩ/20MΩ(AUTO) 4MΩ / 40MΩ |
±(1%+5)
±(1%+5) ±(2%+5) |
|
Battery Test
|
1.5V / 9V
|
1.5V / 9V
|
1.5V / 19V
|
±(2.5%+5)
|
|
Temperature (°C)
|
-
|
(-40°C ~ 1000°C)
|
(-40°C ~ 1000°C)
|
±(1.5%+4)
|
|
Temperature (°F)
|
-
|
(-58°F ~ 1832°F)
|
(-58°F ~ 1832°F)
|
±(2%+4)
|
|
Capacitance (F)
|
- |
- |
40nF ~ 400nF ~ 400uF 4000uF ~ 40000uF
|
±(4%+5)
±(8%+5) |
|
AC/DC600A(CurrentClamp)
|
-
|
-
|
0.1A~600.0A (1A=1mV AC / DC)
|
±(3%+5)
|
|
FEATURES
|
||||
|
Display Counts
|
2000
|
2000
|
4000
|
|
|
Auto Range
|
Manual
|
Semi-Automatic
|
Semi-Automatic
|
|
|
True RMS
|
-
|
|||
|
Connuity / Diode
|
have
|
|||
|
Backlight / Torch
|
have
|
|||
|
Power
|
AA1.5V×2
|
|||
|
Category Ratings
|
CAT III 300V CAT II 600V
|
|||
|
DCV
Range |
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
200.0mV
|
200.0mV
|
400.0mV
|
0.1mV
|
±(0.5%+5)
|
|
|
2.000V
|
2.000V(AUTO)
|
4.000V(AUTO)
|
0.001V
|
||
|
20.00V
|
20.00(AUTO)
|
40.00(AUTO)
|
0.01V
|
||
|
200.0V
|
300.0V(AUTO)
|
400.0V(AUTO)
|
0.1V
|
||
|
600V
|
600V
|
1000V
|
1V
|
||
|
Input protection
|
Impedance10MΩ；600Vrms;750Vrms(FR133E)
|
||||
|
ACV
Range |
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
-
|
2.000V(AUTO)
|
4.000V(AUTO)
|
0.001V
|
±(0.8%+5)
400Hz |
|
|
-
|
20.00V(AUTO)
|
40.00V(AUTO)
|
0.01V
|
||
|
200V
|
300V(AUTO)
|
400V(AUTO)
|
0.1V/1V
|
±(1.2%+5)
400Hz |
|
|
600V
|
600V
|
750V
|
1V
|
||
|
-
|
True/RMS
|
True/RMS
|
-
|
-
|
|
|
Input protection
|
Impedance10MΩ；600Vrms;750Vrms(FR133E)
|
||||
|
Hz
Range |
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
-
|
-
|
10.00Hz
|
0.01Hz
|
±(0.5%+5)
|
|
|
-
|
-
|
100.0Hz
|
0.1Hz
|
||
|
-
|
-
|
1.000KHz
|
0.001KHz
|
||
|
-
|
-
|
40KHz
|
0.01KHz
|
||
|
Input protection
|
600Vrms;750Vrms(FR133E)
|
||||
|
Ω
Range |
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
200Ω
|
200.0Ω
|
400.0Ω
|
0.1Ω
|
±(0.8%+5)
|
|
|
2.000KΩ
|
2.000KΩ（AUTO）
|
4.000KΩ（AUTO）
|
0.001KΩ
|
||
|
20.00KΩ
|
20.00KΩ（AUTO）
|
40.00KΩ（AUTO）
|
0.01KΩ
|
||
|
200.0KΩ
|
200.0KΩ（AUTO）
|
400.0KΩ（AUTO）
|
0.1KΩ
|
||
|
-
|
-
|
4.000MΩ
|
0.001MΩ
|
±(2%+5)
|
|
|
20.00MΩ
|
20.00MΩ
|
40.00MΩ
|
0.01MΩ
|
||
|
Input protection
|
600Vrms;750Vrms(FR133E)
|
||||
|
Function
|
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
Continuity
|
0.1-30Ω
|
0.1Ω
|
-
|
||
|
Diode
|
0.500V-0.800V
|
0.001V
|
-
|
||
|
NCV
|
50V-600V
|
50V-600V
|
50V-750V
|
0-5cm Non-contact induction
|
|
|
LIVE
|
50V-600V
|
50V-600V
|
50V-750V
|
Measure the live line
|
|
|
Input protection
|
600Vrms;750Vrms(FR133E)
|
||||
|
DCA
Range |
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
2000uA
|
2000uA
|
400.0uA
|
0.1uA
|
±(1%+5)
|
|
|
-
|
-
|
4.000mA(AUTO)
|
0.001mA
|
||
|
-
|
-
|
40.00mA(AUTO)
|
0.01mA
|
||
|
200.0mA
|
200.0mA
|
400.0mA(AUTO)
|
0.1mA
|
||
|
-
|
-
|
4.000A
|
0.001A
|
±(2%+5)
|
|
|
10.00A
|
10.00A
|
10.00A
|
0.01A
|
||
|
Input protection
|
FUSE:200mA/250V;500mA/250V;Φ5x20mm;10A Test time Max 10S
|
||||
|
ACA
Range |
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
2000uA
|
2000uA
|
400.0uA
|
0.1uA
|
±(1%+5)
|
|
|
-
|
-
|
4.000mA(AUTO)
|
0.001mA
|
||
|
-
|
-
|
40.00mA(AUTO)
|
0.01mA
|
||
|
200.0mA
|
200.0mA
|
400.0mA(AUTO)
|
0.1mA
|
||
|
-
|
-
|
4.000A
|
0.001A
|
±(2%+5)
|
|
|
10.00A
|
10.00A
|
10.00A
|
0.01A
|
||
|
Input protection
|
FUSE:200mA/250V;500mA/250V;Φ5x20mm;10A Test time Max 10S
|
||||
|
Battery
Range |
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
1.500V
|
1.500V
|
1.500V
|
0.001V
|
±(2.5%+5)
|
|
|
9.00V
|
9.00V
|
9.00V
|
0.01V
|
||
|
Input protection
|
FUSE:200mA/250V;500mA/250V;Φ5x20mm
|
||||
|
℃/℉
Range |
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
-
|
-40℃-0℃
|
-40℃-0℃
|
1℃
|
4℃
|
|
|
-
|
0℃-100℃
|
0℃-100℃
|
1℃
|
±(1%+4)
|
|
|
-
|
100℃-1000℃
|
100℃-1000℃
|
1℃
|
±(2%+4)
|
|
|
-
|
-40℉-32℉
|
-40℉-32℉
|
1℉
|
5℉
|
|
|
-
|
32℉-212℉
|
32℉-212℉
|
1℉
|
±(1%+5)
|
|
|
-
|
212℉-1832℉
|
212℉-1832℉
|
1℉
|
±(2%+5)
|
|
|
Input protection
|
600Vrms;750Vrms(FR133E)
|
||||
|
Range
|
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
-
|
-
|
4.000nF
|
0.001nF
|
±(4%+5)
|
|
|
-
|
-
|
40.00nF
|
0.01nF
|
||
|
-
|
-
|
400.0nF
|
0.01nF
|
||
|
-
|
-
|
4.000uF
|
0.001uF
|
||
|
-
|
-
|
40.00uF
|
0.01uF
|
||
|
-
|
-
|
400.0uF
|
0.1uF
|
||
|
-
|
-
|
4000uF
|
0.001mF
|
±(8%+5)
|
|
|
-
|
-
|
40000uF
|
0.1mF
|
||
|
Input protection
|
600Vrms;750Vrms(FR133E)
|
||||
|
Current
Clamp |
FR133D
|
FR133C
|
FR133E
|
Resolution
|
Accuracy
|
|
-
|
-
|
4.0A(AD/DC)
|
0.1A
|
±(3%+5)
|
|
|
-
|
-
|
40.0A(AD/DC)
|
0.1A
|
||
|
-
|
-
|
400.0A(AD/DC)
|
0.1A
|
||
|
-
|
-
|
600A(AD/DC)
|
1A
|
||
|
Input protection
|
600Vrms;Current clamp output: 1A/1mV AC
|
||||
